Product Overview
The CHDF horizontal multistage stainless steel pump is equipped with a horizontal extended-shaft motor, featuring axial suction and radial discharge. All wetted components are made of high-quality stainless-steel plates formed by stamping and welding, allowing the pump to handle slightly corrosive liquids. It adopts advanced hydraulic models and precision manufacturing techniques, offering wide application, high efficiency, energy saving, and reliable quality. The pump is designed for industrial and domestic clean water supply systems.
CHDF Series Type Designation
Applications
The CHDF stainless-steel horizontal multistage clean water pump is suitable for both industrial and domestic water systems, including:
– Air-conditioning systems
– Fertilizing and metering systems
– Cooling systems
– Environmental protection applications
– Industrial cleaning
– Water supply and pressure boosting systems
– Water purification and treatment
– Domestic water supply
– Aquaculture and irrigation
– Other specialized uses
Operating Conditions
● Liquid temperature: -15°C to +70°C (standard type), +70°C to +110°C (hot water type)
● Ambient temperature: up to +40°C
● Maximum operating pressure: 10 bar
● Maximum inlet pressure is limited by total operating pressure
● Suitable for thin, clean, non-flammable, and non-explosive liquids without solid particles or fibers
● Can convey mineral water, softened water, pure water, light oil, and low-viscosity chemical liquids
● For liquids with density or viscosity greater than water, a higher-power motor should be used
● The suitability of the pump for a specific liquid depends on chlorine content, pH, temperature, and solvent composition
Structure Diagram
(Product image)
| No. | Part Name | Material | AISI/ASTM | No. | Part Name | Material | AISI/ASTM |
|---|---|---|---|---|---|---|---|
| 1 | Inlet Section | Stainless Steel | AISI304 | 8 | Mechanical Seal | – | – |
| 2 | End Cover | Stainless Steel | AISI304 | 9 | Motor End Cover | Aluminum Alloy | – |
| 3 | Bearing | Tungsten Carbide | – | 10 | Base | Cast Iron | ASTM258 |
| 4 | Impeller | Stainless Steel | AISI304 | 11 | Tie Rod | Stainless Steel | AISI304 |
| 5 | Shaft | Stainless Steel | AISI304 | 12 | Guide Vane | Stainless Steel | AISI304 |
| 6 | Outlet Diffuser | Stainless Steel | AISI304 | 13 | Support Diffuser | Stainless Steel | AISI304 |
| 7 | Outlet Section | Stainless Steel | AISI304 | 14 | Impeller Spacer | Stainless Steel | AISI304 |
Performance Parameters
(Performance table)
| Model | Motor Power (kW) | Head (m) at Flow (m³/h) | ||||||
|---|---|---|---|---|---|---|---|---|
| CHDF2-20 | 0.37 | 19 | 18 | 16 | 14 | 13 | 11 | 9 |
| CHDF2-30 | 0.55 | 28 | 27 | 24 | 21 | 20 | 17 | 14 |
| CHDF4-50 | 1.1 | 46 | 44 | 41 | 38 | 32 | 26 | 20 |
| CHDF8-30 | 1.1 | 29 | 28 | 27 | 25.5 | 22.5 | 20 | 17.5 |
| CHDF16-40 | 4.0 | 50.5 | 49 | 46 | 43 | 40.5 | 36 | 31.5 |
Installation Dimensions
(Installation data table)
Refer to detailed dimensional data provided in the table for each model, including motor type, overall length, height, and weight. Flange connections conform to international standards for easy maintenance and replacement.
Maintenance and Service
1. The inlet pipeline must be airtight without leakage of water or air.
2. Avoid long-term cavitation operation.
3. Do not allow the pump to operate beyond rated flow for extended periods.
4. Regularly monitor motor current to ensure operation within design range.
5. Lubricate bearings after every 500 hours of operation.
6. After long-term use, inspect for mechanical wear, noise, and vibration; replace bearings or seals as necessary.
7. Overhaul interval: approximately one year under normal operation.
Troubleshooting
Problem: Pump not discharging water
Cause: Inlet valve closed, suction blocked, or motor rotating incorrectly.
Solution: Open valves, remove blockage, and verify rotation direction.
Problem: Insufficient flow
Cause: Blocked pipeline or impeller wear.
Solution: Clean and inspect impeller, remove deposits, adjust valve opening.
Problem: Excessive noise or vibration
Cause: Loose mounting or bearing failure.
Solution: Tighten fasteners and replace bearings.
Problem: Overheating motor
Cause: Overload, friction, or low voltage.
Solution: Adjust flow, check bearings, and stabilize voltage.
Problem: Leakage
Cause: Worn mechanical seal or loose bolts.
Solution: Replace seals and retighten bolts.
OEM & Custom Solutions
We provide OEM/ODM customization, including stainless-steel materials, special voltages (220V/415V/460V), and high-temperature configurations. Optional explosion-proof motors, control panels, and custom packaging or labeling are available. All products meet ISO and CE export standards, ensuring quality and reliability for industrial and municipal use.
FAQs for Oversea Buyers
Q: What’s the main advantage of the CHDF horizontal multistage pump?
A: It provides high efficiency, stable operation, and corrosion resistance using all-stainless-steel construction and precision hydraulic design.
Q: What liquids can it handle?
A: Clean water, mineral water, light oil, and slightly corrosive liquids with low viscosity.
Q: What’s the temperature range?
A: Standard type: -15°C to +70°C; hot water type: up to +110°C.
Q: Does it require frequent maintenance?
A: No, only regular bearing lubrication and seal inspection are needed for long-term reliability.
Q: Can it be customized for special voltages?
A: Yes, we support 220V, 415V, 460V, and other customized power options for export.
Q: Is the pump suitable for continuous operation?
A: Yes, it is designed for stable long-term operation under high efficiency and low noise conditions.
Q: Which markets use this pump?
A: The CHDF series is widely exported to Southeast Asia, the Middle East, Africa, and South America for water treatment, HVAC, and industrial systems.
